Description
Product introduction：
0-24W series GS horizontal switching power supply, in line with GS EU switching power supply certification standards, with overload protection, overvoltage protection, constant voltage function, constant current function, products are mainly used in lamps, fitness equipment, small household appliances, battery charging, motors, etc. field.
Specifications:
Model | GP-SWXXXDCXXXX(EU),IP20 SERIES |
Input Voltage | 220-240V |
Input Frequency | 50Hz |
Output Voltage | 5-36V |
Output Current | 20-1500MA |
Output Power | 24W Max |
Special Function | OCP,SCP |
HIPOT Testing | 3750Vac/5mA/Min |
Ac Pin Type | GS |
Mean Time Between Failures | 50,000 HOURS AT FULL LOAD AND 25°C AMBIENT |
Application | CLASS 2 POWER UNIT |
Safety Certification | EN61347，EN61558，EN60335 |
Safety Regulations And Electromagnetic Interference Standards | EN 55015:2013+A1:2015;EN 61547:2009;EN 61000-3-2:2014;EN 61000-3-3:2013 |
Energy Efficiency Standards | VI |
Output Method | USB, DC JACK , CORD |
Protection Index | IP20(Indoor use) |
Burn-In | 100% Full Load Burn in |
Operating Temperature | -40~40℃ |
